034Motorsport is proud to unveil an all-new line of Performance Software for MkV Volkswagen GLI/GTI/Eos & 8J/8P Audi A3/TT models equipped with the EA113 2.0T FSI engine!
Flashed directly through your vehicle's OBD-II port, 034Motorsport’s proprietary calibrations for the Bosch MED9 ECU safely and effectively increase the power output of the 2.0T FSI engine. The result is a noticeable improvement in acceleration and throttle response, without any sacrifice in driveability or reliability.
034Motorsport's EA113 2.0T FSI Performance Software was developed entirely in-house on 034Motorsport's Development 8P Audi A3. The calibrations were then refined on multiple enthusiast-owned MkV Volkswagen 2.0T FSI and 8J/8P Audi A3/TT 2.0T FSI vehicles before release.
Software Features
 |
|
 |
 |
|
 |
 |
|
 |
 |
|
 |
034MOTORSPORT EA113 2.0T FSI MED9 ECU PERFORMANCE SOFTWARE COMPARISON
| Stage | Fuel | Max HP | Max TQ | Max HP Gain | Max TQ Gain | Rev Limiter | Speed Limiter |
|---|---|---|---|---|---|---|---|
| Stock | 91 Oct | 205 HP | 216 TQ | NA | NA | 6,800 RPM | 205kph |
| Stage 1 | 91 Oct | 226 HP | 252 TQ | 30 HP @ 4,000 RPM | 40 TQ @ 3,700 RPM | 7,100 RPM | ∞ |
| Stage 2 | 91 Oct | 248 HP | 254 TQ | 44 HP @ 5,800 RPM | 41 TQ @ 4,500 RPM | 7,100 RPM | ∞ |
| Stage 2+ | 91 Oct | 252 HP | 274 TQ | 48 HP @ 4,400 RPM | 62 TQ @ 4,000 RPM | 7,100 RPM | ∞ |
| K04 Turbo | 91 Oct | 309 HP | 313 TQ | 111 HP @ 6,400 RPM | 100 TQ @ 3,700 RPM | 7,100 RPM | ∞ |
034MOTORSPORT EA113 2.0T FSI MED9 ECU PERFORMANCE SOFTWARE STAGE DESCRIPTIONS
STAGE 1
034Motorsport Stage 1 Performance Software for the EA113 2.0T FSI engine is engineered to safely increase horsepower and torque with no hardware modifications required. 034Motorsport's proprietary calibrations increase boost while optimizing timing and fueling maps to extract additional power from the 2.0T FSI engine.
Stage 1 Performance Software features a higher redline of 7,100 RPM, resulting in a broader, more usable powerband. In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in order to provide improved throttle response and allow for more precise throttle modulation.
STAGE 2
034Motorsport Stage 2 Performance Software for the EA113 2.0T FSI engine is engineered to further increase horsepower and torque with the addition of a high-flow downpipe upgrade and performance air intake. 034Motorsport's calibrations optimize the factory ECU for these hardware modifications in order to extract additional power from the 2.0T FSI engine.
Stage 2 Performance Software features a higher redline of 7,100 RPM, resulting in a broader, more usable powerband. In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in order to provide improved throttle response and allow for more precise throttle modulation.
STAGE 2+
034Motorsport Stage 2+ Performance Software for the EA113 2.0T FSI engine is engineered to further increase horsepower and torque with the addition of a high-pressure fuel pump (HPFP) upgrade, high-flow downpipe upgrade, and performance air intake. 034Motorsport's calibrations optimize the factory ECU for these hardware modifications in order to extract additional power from the 2.0T FSI engine.
Stage 2+ Performance Software features a higher redline of 7,100 RPM, resulting in a broader, more usable powerband. In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in order to provide improved throttle response and allow for more precise throttle modulation.
K04 TURBO
034Motorsport K04 Performance Software for the EA113 2.0T FSI engine is engineered to further increase horsepower and torque with the addition of an 8P Audi S3 2.0T FSI K04 turbocharger, 8P Audi S3 2.0T FSI fuel injectors, high-pressure fuel pump (HPFP) upgrade, high-flow downpipe upgrade, and performance air intake. 034Motorsport's calibrations optimize the factory ECU for these hardware modifications in order to extract additional power from the 2.0T FSI engine.
K04 Performance Software features a higher redline of 7,100 RPM, resulting in a broader, more usable powerband. In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in order to provide improved throttle response and allow for more precise throttle modulation.
034MOTORSPORT EA113 2.0T FSI MED9 ECU PERFORMANCE SOFTWARE HARDWARE REQUIREMENTS
| Stage | Required Modifications | Recommended Modifications |
|---|---|---|
| Stage 1 |
|
|
| Stage 2 |
|
|
| Stage 2+ | ||
| K04 Turbo |
034Motorsport Dynamic+ End User Flashing Kit
034Motorsport's Dynamic+ End User Flashing Kit allows customers to install their 034Motorsport Dynamic+ Performance Software themselves. In addition, End User Flashing allows Dynamic+ Performance Software customers to receive and install software updates and revisions, flash back to stock, or upgrade to the next stage of performance software for their vehicle.
Requirements for End User Flashing:
- Windows 7 or Windows 10 Laptop with Available USB Port
- Power Supply for Laptop
- Secure Wired (Or Very Stable WiFi) High-Speed Internet Connection
- CTEK Trickle Charger (Or Similar)
- Available Electrical Outlets
034Motorsport End User Flashing Kit Contents:
- 034Motorsport OBD-II Adapter
- USB-A to USB-B Cable
- Carrying Case
- User Credentials (Provided Via Email)
EMISSIONS DISCLAIMER
- This product is sold for racing use as well as use on vehicles not registered for on highway use.
- By purchasing this product, you understand that this product is sold for racing use as well as used on vehicles not registered for on highway use, and that it is not legal for use on highway or street vehicles.
Please Note: Crackle results may vary based on ECU box code variations, fuels, exhaust setup, and geographic locations. 034Motorsport also offers no-crackle files available upon request. Please email Tuning@034Motorsport.com for more information if you do not see them in your flashing portal.
