034 Motorsport Dynamic+ TCU Software Upgrade for AL552 ZF8 Transmission, B9/B9.5 RS4/RS5 | 034-103-2562

PRODUCT DESCRIPTION:

034Motorsport is proud to offer Stage 2 TCU Software for B9/B9.5 Audi RS4 or RS5 models equipped with the AL552 8-Speed ZF8 transmission!

Flashed directly through your vehicle’s OBD-II port, 034Motorsport’s proprietary calibrations for the AL552 TCU safely and effectively optimize its operation for Stage 1/1+ Performance ECU Software The result is a noticeable improvement in acceleration, without sacrificing comfort or reliability.

034Motorsport's AL552 Performance Software was developed entirely in-house on 034Motorsport's Development B9 and B9.5 Audi RS5. The calibrations continue to be refined and tested on enthusiast-owned beta tester cars around North America.

034MOTORSPORT B9/B9.5 AUDI RS4/RS5 AL552 ZF8 STAGE DESCRIPTIONS:

034Motorsport Stage 1 Transmission Performance Tuning Software for the AL552 is included in the Dynamic+ Tuning Bundle with our Stage 1/1+ ECU software.

The Dynamic+ ECU Tuning accurately reports torque values to the TCU to ensure that all safety systems are intact in both control units, and the added torque from tuning is properly adjusted for when driving/shifting, including all safety systems designed to protect the engine and transmission. This results in better shift quality as the transmission is not having to reduce engine torque or having to adapt to misreported inputs.

The 034Motorsport Stage 2 Transmission Performance Tuning Software for the AL552 is designed to further improve the drivability and performance of your Dynamic+ Tuned Audi B9/B9.5 Audi RS4 or RS5. Dynamic+ Stage 2 TCU Software can be used with our Stage 1/1+ ECU software.

034Motorsport Stage 2 TCU Tuning further improves shifting performance and speed for casual and track driving in all driving modes. Dynamic+ Tuning also activates AMAX shifting to ensure the quickest and most efficient shifting strategies while launching your vehicle. These changes result in a significant improvement in acceleration, and lower 0-60 and ¼ mile times.

The 034Motorsport Stage 3 Transmission Performance Tuning Software for the AL552 is designed to further improve the drivability and acceleration performance of your Stage 3 Dynamic+ Tuned Audi B9/B9.5 RS4 or RS5. Dynamic+ Stage 3 TCU Software is designed to be used with Dynamic+ Stage 3 ECU Software. 034Motorsport Stage 3 TCU Tuning further optimizes shift points under partial and full throttle to keep the TTE720 Turbochargers in their peak power band, and raises the redline to 7,200 for maximum performance with the larger turbocharger!

PERFORMANCE TCU STAGE 2 SOFTWARE FEATURES:

• As with any automatic transmission vehicle, the ECU and TCU computers work synchronously to properly apply torque to the vehicle's drivetrain in a safe and reliable manner. Within both the ECU and TCU, there are factory safety tables that limit overall torque output based upon what the factory first tuned the car for. The ECU reports the output of torque from the engine to the TCU, and the TCU decides if this is suitable, or too much. If it is too much, the TCU will command the ECU to reduce torque output based upon its safety tables.


• 034Motorsport takes a holistic approach with its Dynamic+ Tuning, and aims to retain as many OEM safety protocols as possible. While it is possible to tune around the factory TCU torque limiters from the ECU side, this is done at the expense of torque safety features that are integral in keeping your transmission running safely. 034Motorsport’s calibrators tune the ECU to work with the TCU to provide accurate torque values, and recalibrate the appropriate safety ranges for the TCU. Taking these extra steps to retain OEM safety systems on the ECU and TCU side is just one of the many reasons that Dynamic+ software provides substantial yet reliable performance increases.

• In order to take advantage of the increased powerband from the turbochargers, Dynamic+ Tuning optimizes the shift points in all driving modes to maximize acceleration during wide open throttle scenarios.


• To further enhance the acceleration of your Audi, the ZF8 shift times are dramatically decreased in all driving modes, which ultimately results in quicker acceleration. Shift times are now up to 70% faster!


• Shift pressures are also increased in Sport Mode to maximize performance. In Sport Mode, you will notice less lazy shifts, more firm shifts, which ultimately results in quicker acceleration.

• The launch stall RPM has been raised for a significant increase in force, allowing you to get off the line as fast as possible.

• The delay time between launch control activations has been shortened. This is useful when drag racing to heat up tires using launch control, and re-activate quickly before launching down the drag strip!

034MOTORSPORT STAGE 2 AL552 PERFORMANCE TCU SOFTWARE COMPARISON:
