034Motorsport Performance Software - Audi / B8 / 2.0TFSI (EA888 Gen 2) / A4 / A5 / Q5 | 034-103-2781

PRODUCT DESCRIPTION:

The 034Motorsport Dynamic+ Tuning Software for Audi B8 A4/A5/Q5 equipped with the EA888 Gen 2 2.0T inline four engine is designed to transform the driving experience of your vehicle! Flashed directly through your vehicle’s OBD-II port, 034Motorsport’s proprietary calibrations for the ECU safely and effectively increase the power output of the turbocharged inline four in a refined manner. The result is a significant improvement in acceleration and throttle response, without any sacrifice in driveability or reliability.

034Motorsport Audi B8 A4/A5/Q5 EA888 Gen 2 2.0T Dynamic+ Performance Software was developed entirely in-house on 034Motorsport's Development B8 A5. The calibrations were then refined on multiple enthusiast-owned beta tester cars around North America.

034Motorsport engineers develop special inhouse tools that allow us to access the firmware and maps inside the factory ECU, this level of engineering is required to prevent work-arounds and bandaids that many aftermarket companies resort to. With our own in-house software development team creating tools to read, write, log, and modify the software on these ECU’s 034Motorsport engineers and optimizes the software and calibrations just like Audi engineers would, by accessing the source of how the ECU controls the engine and making changes at the base level.

This is the ONLY way 034Motorsport can ensure our calibrations meet our high standards for ultimate power with smooth drivability, perfect function, reliability and added functions and features even beyond what the factory programming can provide.

NOTE: The E85 calibration is not a flex-fuel style tune. The tune will work with E85 directly from the pump, both summer and winter blends (ethanol content can vary from E60-E85). This tune requires only E85 be pumped into the fuel tank. Gasoline blends and race fuel mixtures should not be used, and engine damage could occur if the incorrect fuel or octane is used. We strongly recommend an ethanol content gauge be used so that you can monitor the actual ethanol content at the pump you are using.

When switching fuels, it takes about 20-30 minutes of normal driving for the new tank of fuel to fully circulate through the system when filled at empty. Please minimize load (don’t floor it!) until you have driven the car for at least 30 minutes. Ethanol content analyzers installed close to the fuel rail will also help you see when the ethanol has fully run through the system.

THERMAL MANAGEMENT SAFETY STRATEGIES:

With increased power, comes increased heat. With increased heat, comes the need for additional management. For charge air temperature, 034Motorsport has implemented key safety features to keep your engine running optimally and safely in virtually any condition - just like the OEM calibration. Substantial effort was spent on balancing the trade off of charge temp for power, and improving the compressor efficiency so that it doesn't generate too much charge temp.

Charge Air Temp: When the charge temp exceeds 80*C there is a reduction in power output. When the charge temp exceeds 85*C there is a more significant reduction in power output. This charge temp limitation is there to prevent knock events from excessive charge temps, which can severely damage a motor. With these safety measures in place, you can confidently drive your car, from the top of Pikes Peak to Death Valley, knowing the factory ECU has optimal performance and safety covered.

FUEL SYSTEM OPTIMIZATION:

While E85 provides substantial increases in power, it requires about 30% more fuel than standard pump gasoline per ignition cycle. Utilizing a variety of fuel stratified injection strategies, 034Motorsport calibrators have further optimized the factory fueling system to be able to adequately support full E85 on factory hardware for Stage 1 & Stage 2 tunes.

SOFTWARE FEATURES:

	Increased Horsepower & Torque Throughout the Powerband
	Improved Power Delivery, Acceleration, and Driving Characteristics

	Available in 91 Octane, 93 Octane, and E85 Calibrations
	Left Foot Braking Enabled

	Refined Throttle Mapping for Enhanced Throttle Response & Precision
	Speed Limiter Removed for Increased Top Speed

	Track-Tested Calibrations Ensure Consistent Power Delivery
	Crackle Overrun Enabled! *No-Crackle Files Available Upon Request

034Motorsport Stage 1 Performance Software for the EA888 Gen 2 2.0T engine running pump gas or ethanol is engineered to safely increase the horsepower and torque with no additional hardware required.

In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in order to provide improved throttle response and allow for more precise throttle modulation and further control of the vehicle when driving on track. Due to the limitations of the stock turbocharger on the EA888 Gen 2, the rev limiter was not adjusted.

034Motorsport EA888 Gen 2 2.0T Performance Software is flashed via the factory OBD-II port, and does not require any physical modification of the factory ECU. Stage 1 is available in 91 Octane, 93 Octane, and E85. ALL FILES ARE US (MON+RON) RATING, ROW OCTANE RATINGS MAY DIFFER. IF YOU ARE A UK/ROW CUSTOMER, PLEASE EMAIL TUNING@034MOTORSPORT.COM FOR ASSISTANCE ON FUEL MAP SELECTION.

STAGE 2

034Motorsport Stage 2 Performance Software for the EA888 Gen 2 2.0T engine is engineered to further increase horsepower and torque output over Stage 1 levels with the addition of an Upgraded Intake System, an Upgraded Intercooler, and an Upgraded High Flow Catted Downpipe. As with all 034Motorsport calibrations, the proprietary safety calibrations yield additional power from the 2.0T engine without increased risk to the factory Engine, Transmission, and Drivetrain. The resulting gains over stage 1 with this added hardware make for an even more profound transformation over Stock or Stage 1!

Please Note: Crackle results may vary based on ECU box code variations, fuels, exhaust setup, and geographic locations. 034Motorsport also offers no-crackle files available upon request. Please email Tuning@034Motorsport.com for more information if you do not see them in your flashing portal.
